Draw a sketch-style glycan cartoon

draw_cartoon_sketch() uses ggsketch::ggsketch-package geoms to give a glycan cartoon hand-drawn strokes and patterned residue fills. Its glycan layout, annotations, orientation, and sizing are otherwise identical to draw_cartoon().

Usage

draw_cartoon_sketch(
  structure,
  ...,
  show_linkage = TRUE,
  orient = c("left", "right", "up", "down"),
  highlight = NULL,
  style = style_glydraw(),
  roughness = 1,
  bowing = 1,
  n_passes = 2L,
  seed = NULL,
  fill_style = "pencil_shade",
  hachure_angle = 45,
  hachure_gap = 0.03,
  fill_weight = 0.5,
  medium = NULL,
  red_end = NULL
)

Arguments

structure

A glyrepr::glycan_structure() scalar, or a string of any glycan structure text nomenclatures supported by glyparse::auto_parse().

...

Ignored.

show_linkage

Show glycosidic linkage annotations or not. Defaults to TRUE. Substituent annotations are always shown.

orient

Direction in which the glycan extends from its reducing end: one of "left", "right", "up", or "down". Defaults to "left".

highlight

An integer vector specifying the node indices to highlight. This argument is applicable only when structure is a glyrepr::glycan_structure(). Note that for a glyrepr::glycan_structure(), the node indices correspond exactly to the monosaccharides in its printed IUPAC nomenclature. For example, given glyrepr::as_glycan_structure("Gal(b1-3)[GlcNAc(b1-6)]GalNAc(a1-"), setting highlight = c(1, 3) will highlight the "Gal" and "GalNAc" nodes.

style

A style_glydraw() object that controls the cartoon's visual appearance.

roughness

Non-negative roughness of the hand-drawn strokes. Zero produces straight strokes. Hex circle outlines are automatically softened to keep their curved borders smooth.

bowing

Non-negative multiplier controlling how much strokes bow.

n_passes

Number of times each sketch stroke is drawn.

seed

An optional integer seed for reproducible sketch strokes. When NULL, ggsketch uses getOption("ggsketch.seed", 1L).

fill_style

Residue fill pattern. Defaults to "pencil_shade". See ggsketch::geom_sketch_polygon() for the available styles.

hachure_angle

Angle of patterned fill lines in degrees.

hachure_gap

Gap between patterned fill lines as a proportion of the node diameter. Defaults to 0.03.

fill_weight

Stroke weight of patterned fill lines.

medium

Optional drawing medium for linkage and reducing-end strokes. See ggsketch::sketch_media() for the available media.

red_end

Reducing-end annotation. NULL, the default, uses red_end from style. A non-NULL value overrides style$red_end. Ignored when style$red_end_length is 0. To annotate an amino-acid sequence, tag its single glycosite as, for example, "ABC<site>D</site>EFG".

Value

A glydraw_cartoon ggplot2 object.

Details

Sketch cartoons always use a handwriting font, ignoring font_family in style. They prefer an installed sketch-style font that contains Greek alpha, Greek beta, and decimal digits so all linkage labels use one font.

Examples

if (requireNamespace("ggsketch", quietly = TRUE)) {
  draw_cartoon_sketch("Gal(b1-3)GalNAc(a1-", seed = 1)
}
